2.5KW DC Electronic Load Bank
DE-ELB-2.5KWDC
Touch Screen HMI::
✓ Display: 7-inch or larger high-resolution Color touch screen.
✓ Programming: Intuitive interface for setting and adjusting voltage, current, and load profiles.
✓ Monitoring: Real-time display of electrical parameters including voltage, current, power factor, and temperature.
✓ Data Logging: Capability to log real-time data, historical data, and generate comprehensive test reports.
✓ Alarms and Notifications: Visual and audible alerts for system faults, load changes, and other critical conditions
| MODEL | DE-ELB-2.5KWDC |
|---|---|
| Technical Specification | |
| parameters | |
| Open Circuit voltage | 0V-36V |
| On load Voltage | 2V-36V |
| Load Current Range | 0A-450A |
| Power Ratings | 2.5KW |
| Modes of Operation | Constant Current |
| Programmable parameters | |
| Test Duration | 0-2 hours |
| Time (Min Load Pulse) | 10mSec |
| Time (Max Load Pulse) | 2 hours |
| No. of Load Steps | Min 1, Max 300 |
| Load Realization time | < 0.5mSec |
| Data Acquisition Parameters | |
| Voltage Range | 2V-36V DC |
| Voltage Resolution | 0.5V |
| Voltage Accuracy | ±0.5%(FS) |
| Current Range | 0A-450A |
| Current Resolution | 0.5A |
| Current Accuracy | ±0.5%(FS) |
| Power rating | 2.5KW |
| Data Acquisition Sampling Rate | 1mSec, 10mSec & 1000mSec |
| Indications | |
| Load ON,Low Battery,Over Current,Over Power,Source reverse | |
| COOLING | Forced Air Cooling(6inch dc fan 300 OR MORE CFM) |
| NPUT TERMINALS | Heavy duty copper bus bar Terminals. |
| Test Termination Methods | |
| Emergency Cut Off | Circuit Breaker |
| Protections | Over voltage,Over Current,Over Power, Reverse Polarity |
| Max temperature with standing | 55 ◦C |
| Noise and vibrations | Fan noise |
